Types Of Solar Panels

Solar panels, which convert sunlight into electricity, come in several types, each with its own characteristics and uses.


1. Monocrystalline Solar Panels (Mono-SI)

FeatureDetails
MaterialSingle-crystal silicon cells.
EfficiencyTypically 15-22%, the highest efficiency among all types.
Lifespan25+ years, longest lifespan.
AppearanceUniform black color, rounded edges.
PerformanceHigh performance, better in low-light conditions.
CostHigher cost due to complex manufacturing process.
ApplicationsResidential, commercial, and utility-scale installations.


2. Polycrystalline Solar Panels (Poly-SI)

FeatureDetails
MaterialSilicon crystals melted together.
EfficiencyTypically 13-16%, lower than monocrystalline.
Lifespan20-25 years.
AppearanceBlue hue with speckled, square-shaped cells.
PerformanceLower performance in high temperatures, less efficient in low-light.
CostLower cost due to simpler manufacturing process.
ApplicationsResidential and commercial installations.


3. Thin-Film Solar Panels


a. Amorphous Silicon (a-Si)

FeatureDetails
MaterialNon-crystalline silicon.
EfficiencyTypically 6-8%, lowest among the main types.
Lifespan10-20 years.
AppearanceFlexible and lightweight, can be black or dark brown.
PerformancePerforms better in high temperatures and low-light conditions.
CostLower cost, easy to produce.
ApplicationsPortable solar devices, building-integrated photovoltaics (BIPV), consumer electronics.


b. Cadmium Telluride (CdTe)

FeatureDetails
MaterialCadmium telluride.
EfficiencyTypically 9-11%.
Lifespan10-20 years.
AppearanceDark brown or black, usually with a glass substrate.
PerformancePerforms well in low-light and high-temperature conditions.
CostLower cost, but cadmium is a toxic heavy metal.
ApplicationsLarge-scale utility projects, BIPV.


c. Copper Indium Gallium Selenide (CIGS)

FeatureDetails
MaterialCopper indium gallium selenide.
EfficiencyTypically 10-12%.
Lifespan10-20 years.
AppearanceFlexible and lightweight, usually dark.
PerformanceHigh efficiency among thin-film, good in low-light conditions.
CostHigher cost compared to other thin-film panels, but less toxic materials.
ApplicationsPortable solar devices, BIPV, automotive applications.


Array ( [0] => Array ( [id] => 3 [catid] => 16 [typeid] => 0 [info_flag] => 438231445459308544 [title] => N Type Bifacial Solar Panel (570W-585W) [style] => [thumb] => data/watermark/main/20240423/66276dc89bd7b.jpg [keywords] => [tags] => [description] => [url] => n-type-solar-panel/N-type-bifacial-solar-panel-570w-585w.html [moveurl] => index.php?g=Content&m=Pagedis&a=shows&catid=16&id=3 [listorder] => 0.00 [status] => 99 [istop] => 1 [recommend] => 0 [sysadd] => 1 [islink] => 0 [username] => admin66 [inputtime] => 1713941718 [updatetime] => 1713941718 [update_time] => 1719385569 [views] => 0 [yesterdayviews] => 0 [dayviews] => 0 [weekviews] => 0 [monthviews] => 0 [viewsupdatetime] => 0 [seotitle] => N Type Bifacial Solar Panel (570W-585W) [seokeywords] => N Type Bifacial Solar Panel (570W-585W) [seodescription] => N-type Bifacial solar panels have gained significant traction due to their numerous advantages, Especially their ability to enhance energy production through their high efficiency. [seourl] => N-type-bifacial-solar-panel-570w-585w [isdelay] => 0 [is_del] => 0 [seoh1] => [product_one_catid] => [product_two_catid] => [product_three_catid] => ) [1] => Array ( [id] => 7 [catid] => 17 [typeid] => 0 [info_flag] => 443343740459945984 [title] => Small Solar Panels and Customization Solar Panels [style] => [thumb] => data/watermark/main/20240618/6670e72c01ffe.png [keywords] => [tags] => [description] => [url] => small-solar-panel/small-solar-panels-and-customization-solar-panels.html [moveurl] => index.php?g=Content&m=Pagedis&a=shows&catid=17&id=7 [listorder] => 0.00 [status] => 99 [istop] => 0 [recommend] => 0 [sysadd] => 1 [islink] => 0 [username] => admin68 [inputtime] => 1715160584 [updatetime] => 1715160584 [update_time] => 1718675254 [views] => 0 [yesterdayviews] => 0 [dayviews] => 0 [weekviews] => 0 [monthviews] => 0 [viewsupdatetime] => 0 [seotitle] => Small Solar Panels and Customization Solar Panels Supplier China [seokeywords] => Small Solar Panels and Customization Solar Panels Supplier [seodescription] => To cater to the diverse needs of our clients and varying application scenarios, we also offer small solar panels that are suitable for use in solar street lights, small DC LEDs, solar water pumps, and other similar applications. We can provide from 5W- 720W. [seourl] => small-solar-panels-and-customization-solar-panels [isdelay] => 0 [is_del] => 0 [seoh1] => [product_one_catid] => [product_two_catid] => [product_three_catid] => ) [2] => Array ( [id] => 8 [catid] => 22 [typeid] => 0 [info_flag] => 444025745266839552 [title] => Solar Street Light [style] => [thumb] => data/watermark/main/20240510/663dc10c4e1b0.jpg [keywords] => [tags] => [description] => [url] => solar-street-light/solar-street-light.html [moveurl] => index.php?g=Content&m=Pagedis&a=shows&catid=22&id=8 [listorder] => 0.00 [status] => 99 [istop] => 0 [recommend] => 0 [sysadd] => 1 [islink] => 0 [username] => admin68 [inputtime] => 1715323187 [updatetime] => 1715323187 [update_time] => 1715323187 [views] => 0 [yesterdayviews] => 0 [dayviews] => 0 [weekviews] => 0 [monthviews] => 0 [viewsupdatetime] => 0 [seotitle] => Solar Street Light Factory [seokeywords] => Solar Street Light Wholesaler [seodescription] => Solar Street Light Wholesaler. If you are interested in our products, please contact us and we will provide you with the best quality products and the best service! [seourl] => solar-street-light [isdelay] => 0 [is_del] => 0 [seoh1] => [product_one_catid] => [product_two_catid] => [product_three_catid] => ) [3] => Array ( [id] => 6 [catid] => 16 [typeid] => 0 [info_flag] => 443343536285421568 [title] => N-type Monofacial (570W-590W) [style] => [thumb] => data/watermark/main/20240508/663b45c018544.jpg [keywords] => [tags] => [description] => [url] => n-type-solar-panel/n-type-monofacial-570w-590w.html [moveurl] => index.php?g=Content&m=Pagedis&a=shows&catid=16&id=6 [listorder] => 0.00 [status] => 99 [istop] => 0 [recommend] => 0 [sysadd] => 1 [islink] => 0 [username] => admin68 [inputtime] => 1715160535 [updatetime] => 1715160535 [update_time] => 1715160535 [views] => 0 [yesterdayviews] => 0 [dayviews] => 0 [weekviews] => 0 [monthviews] => 0 [viewsupdatetime] => 0 [seotitle] => N-type Monofacial (570W-590W) [seokeywords] => N-type Monofacial (570W-590W) [seodescription] => Compared to N-TYPE bifacial solar panels, monofacial solar panels offer a simpler installation process. [seourl] => n-type-monofacial-570w-590w [isdelay] => 0 [is_del] => 0 [seoh1] => [product_one_catid] => [product_two_catid] => [product_three_catid] => ) [4] => Array ( [id] => 23 [catid] => 20 [typeid] => 0 [info_flag] => 501277003249487872 [title] => 48V 200Ah Stacked Lithium Battery [style] => [thumb] => data/watermark/main/20241015/670e07f2267ae.jpg [keywords] => [tags] => [description] => [url] => hybrid-solar-system/48v-200ah-stacked-lithium-battery.html [moveurl] => index.php?g=Content&m=Pagedis&a=shows&catid=20&id=23 [listorder] => 0.00 [status] => 99 [istop] => 0 [recommend] => 0 [sysadd] => 1 [islink] => 0 [username] => jmsolar [inputtime] => 1728972950 [updatetime] => 1728972950 [update_time] => 1728972950 [views] => 0 [yesterdayviews] => 0 [dayviews] => 0 [weekviews] => 0 [monthviews] => 0 [viewsupdatetime] => 0 [seotitle] => 48V 200Ah Stacked Lithium Battery Manufacturer China [seokeywords] => 48V 200Ah Stacked Lithium Battery Supplier [seodescription] => Stacked lithium battery is a new type of lithium-ion battery structure that improves energy density and performance by stacking multiple battery cells together. [seourl] => 48v-200ah-stacked-lithium-battery [isdelay] => 0 [is_del] => 0 [seoh1] => [product_one_catid] => [product_two_catid] => [product_three_catid] => ) [5] => Array ( [id] => 5 [catid] => 15 [typeid] => 0 [info_flag] => 438233749554073600 [title] => 550-560W Solar Panels [style] => [thumb] => data/watermark/main/20240626/667bb7d47a371.png [keywords] => [tags] => [description] => [url] => perc-solar-panel/550-560W Solar Panels.html [moveurl] => index.php?g=Content&m=Pagedis&a=shows&catid=15&id=5 [listorder] => 0.00 [status] => 99 [istop] => 1 [recommend] => 0 [sysadd] => 1 [islink] => 0 [username] => admin66 [inputtime] => 1713942267 [updatetime] => 1713942267 [update_time] => 1719384042 [views] => 0 [yesterdayviews] => 0 [dayviews] => 0 [weekviews] => 0 [monthviews] => 0 [viewsupdatetime] => 0 [seotitle] => 550-560W Solar Panels [seokeywords] => 550-560W Solar Panels [seodescription] => JM Solar, a professional solar integrated solution provider in China, is a high-tech enterprise dedicated to R&D of solar modules, on/off/hybrid solar systems, lithium batteries, and ESS. [seourl] => 550-560W Solar Panels [isdelay] => 0 [is_del] => 0 [seoh1] => [product_one_catid] => [product_two_catid] => [product_three_catid] => ) [6] => Array ( [id] => 19 [catid] => 16 [typeid] => 0 [info_flag] => 461062445931302912 [title] => Topcon Double Glass All Black Solar Panel (565W-585W) [style] => [thumb] => data/watermark/main/20240626/667bbba8af500.png [keywords] => [tags] => [description] => [url] => n-type-solar-panel/Topcon Double Glass All Black Solar Panel (565W-585W).html [moveurl] => index.php?g=Content&m=Pagedis&a=shows&catid=16&id=19 [listorder] => 0.00 [status] => 99 [istop] => 0 [recommend] => 0 [sysadd] => 1 [islink] => 0 [username] => Grace [inputtime] => 1719385053 [updatetime] => 1719385053 [update_time] => 1719385053 [views] => 0 [yesterdayviews] => 0 [dayviews] => 0 [weekviews] => 0 [monthviews] => 0 [viewsupdatetime] => 0 [seotitle] => Topcon Double Glass All Black Solar Panel (565W-585W) [seokeywords] => Topcon Double Glass All Black Solar Panel (565W-585W) [seodescription] => N-type Bifacial solar panels have gained significant traction due to their numerous advantages, Especially their ability to enhance energy production through their high efficiency. [seourl] => Topcon Double Glass All Black Solar Panel (565W-585W) [isdelay] => 0 [is_del] => 0 [seoh1] => [product_one_catid] => [product_two_catid] => [product_three_catid] => ) [7] => Array ( [id] => 18 [catid] => 15 [typeid] => 0 [info_flag] => 461055355284230144 [title] => 530-550W Full Black Bifacial Solar Panels [style] => [thumb] => data/watermark/main/20240626/667bb9bb101f8.png [keywords] => [tags] => [description] => [url] => perc-solar-panel/530-550W Full Black Bifacial Solar Panels.html [moveurl] => index.php?g=Content&m=Pagedis&a=shows&catid=15&id=18 [listorder] => 0.00 [status] => 99 [istop] => 0 [recommend] => 0 [sysadd] => 1 [islink] => 0 [username] => Grace [inputtime] => 1719383362 [updatetime] => 1719383362 [update_time] => 1719384531 [views] => 0 [yesterdayviews] => 0 [dayviews] => 0 [weekviews] => 0 [monthviews] => 0 [viewsupdatetime] => 0 [seotitle] => 530-550W Full Black Bifacial Solar Panels [seokeywords] => 530-550W Full Black Bifacial Solar Panels [seodescription] => 530-550W Full Black Bifacial Solar Panels [seourl] => 530-550W Full Black Bifacial Solar Panels [isdelay] => 0 [is_del] => 0 [seoh1] => [product_one_catid] => [product_two_catid] => [product_three_catid] => ) [8] => Array ( [id] => 21 [catid] => 20 [typeid] => 0 [info_flag] => 501237488342405120 [title] => 51.2V 200Ah Power Wall Lithium Battery Bank [style] => [thumb] => data/watermark/main/20241015/670de3acc218d.png [keywords] => [tags] => [description] => [url] => hybrid-solar-system/51-2v-200ah-power-wall-lithium-battery-bank.html [moveurl] => index.php?g=Content&m=Pagedis&a=shows&catid=20&id=21 [listorder] => 0.00 [status] => 99 [istop] => 0 [recommend] => 0 [sysadd] => 1 [islink] => 0 [username] => jmsolar [inputtime] => 1728963529 [updatetime] => 1728963529 [update_time] => 1728963529 [views] => 0 [yesterdayviews] => 0 [dayviews] => 0 [weekviews] => 0 [monthviews] => 0 [viewsupdatetime] => 0 [seotitle] => 51.2V 200Ah Power Wall Lithium Battery Bank Manufacturer China [seokeywords] => 51.2V 200Ah Power Wall Lithium Battery Bank Supply [seodescription] => JM lithium battery adopts high quality lithium iron phosphate battery core, equipped with only BMS battery management system, long cycle life, high safety performance, exquisite appearance, free combination, easy installation, LCD display, battery operation data visualization etc. [seourl] => 51-2v-200ah-power-wall-lithium-battery-bank [isdelay] => 0 [is_del] => 0 [seoh1] => [product_one_catid] => [product_two_catid] => [product_three_catid] => ) [9] => Array ( [id] => 16 [catid] => 20 [typeid] => 0 [info_flag] => 455930634284699648 [title] => Hybrid Inverter [style] => [thumb] => data/watermark/main/20240612/66690fe2d9988.jpg [keywords] => [tags] => [description] => [url] => hybrid-solar-system/Hybrid Inverter.html [moveurl] => index.php?g=Content&m=Pagedis&a=shows&catid=20&id=16 [listorder] => 0.00 [status] => 99 [istop] => 0 [recommend] => 0 [sysadd] => 1 [islink] => 0 [username] => Grace [inputtime] => 1718161533 [updatetime] => 1718161533 [update_time] => 1718161533 [views] => 0 [yesterdayviews] => 0 [dayviews] => 0 [weekviews] => 0 [monthviews] => 0 [viewsupdatetime] => 0 [seotitle] => Hybrid Inverter [seokeywords] => Hybrid Inverter [seodescription] => JM Solar, a professional solar integrated solution provider in China, is a high-tech enterprise dedicated to R&D of solar modules, on/off/hybrid solar systems, lithium batteries, and ESS. [seourl] => Hybrid Inverter [isdelay] => 0 [is_del] => 0 [seoh1] => [product_one_catid] => [product_two_catid] => [product_three_catid] => ) [10] => Array ( [id] => 11 [catid] => 28 [typeid] => 0 [info_flag] => 444027307196289024 [title] => 3KW-10KW Solar Systems for Home [style] => [thumb] => data/watermark/main/20240510/663dc29124687.jpg [keywords] => [tags] => [description] => [url] => residential-solar-system1/3KW-10KW-Solar-Systems-for-Home.html [moveurl] => index.php?g=Content&m=Pagedis&a=shows&catid=28&id=11 [listorder] => 0.00 [status] => 99 [istop] => 0 [recommend] => 0 [sysadd] => 1 [islink] => 0 [username] => admin68 [inputtime] => 1715323559 [updatetime] => 1715323559 [update_time] => 1718849375 [views] => 0 [yesterdayviews] => 0 [dayviews] => 0 [weekviews] => 0 [monthviews] => 0 [viewsupdatetime] => 0 [seotitle] => Residential Solar System Exporter China [seokeywords] => Residential Solar System Exporter China [seodescription] => There are three types of residential solar systems: hybrid solar systems, on-grid solar systems, and off-grid solar systems. [seourl] => 3KW-10KW-Solar-Systems-for-Home [isdelay] => 0 [is_del] => 0 [seoh1] => [product_one_catid] => [product_two_catid] => [product_three_catid] => ) [11] => Array ( [id] => 20 [catid] => 20 [typeid] => 0 [info_flag] => 501216433326395392 [title] => 51.2V 100Ah Lithium Battery [style] => [thumb] => data/watermark/main/20241015/670dd534d4f51.png [keywords] => [tags] => [description] => [url] => hybrid-solar-system/51-2v-100ah-lithium-battery.html [moveurl] => index.php?g=Content&m=Pagedis&a=shows&catid=20&id=20 [listorder] => 0.00 [status] => 99 [istop] => 0 [recommend] => 0 [sysadd] => 1 [islink] => 0 [username] => jmsolar [inputtime] => 1728958509 [updatetime] => 1728958509 [update_time] => 1728959826 [views] => 0 [yesterdayviews] => 0 [dayviews] => 0 [weekviews] => 0 [monthviews] => 0 [viewsupdatetime] => 0 [seotitle] => 51.2V 100Ah Lithium Battery Wholesale [seokeywords] => 51.2V 100Ah Lithium Battery Supplier [seodescription] => Solar batteries are one of the most important elements in hybrid solar system. It stores the extra energy for use in the absence of the sun. [seourl] => 51-2v-100ah-lithium-battery [isdelay] => 0 [is_del] => 0 [seoh1] => [product_one_catid] => [product_two_catid] => [product_three_catid] => ) ) 1

Types Of Solar Panels

4. Bifacial Solar Panels

FeatureDetails
MaterialCan be made from monocrystalline or polycrystalline cells.
EfficiencyHigher overall efficiency as they capture sunlight from both sides.
Lifespan25+ years.
AppearanceTransparent or translucent back sheet, often frameless.
PerformanceEnhanced performance due to dual-sided light capture, good for reflective surfaces.
CostHigher initial cost but potentially higher energy yield.
ApplicationsUtility-scale installations, areas with high reflectivity (e.g., snowy or sandy environments).


5. PERC (Passivated Emitter and Rear Cell) Solar Panels

FeatureDetails
MaterialEnhancement to standard monocrystalline or polycrystalline cells.
EfficiencyTypically 17-23%, higher than traditional monocrystalline.
Lifespan25+ years.
AppearanceSimilar to monocrystalline or polycrystalline panels.
PerformanceImproved efficiency due to passivation layer that reduces electron recombination.
CostModerately higher cost due to advanced manufacturing techniques.
ApplicationsResidential, commercial, and utility-scale installations.


6. BIPV (Building-Integrated Photovoltaics)

FeatureDetails
MaterialVarious materials, can be monocrystalline, polycrystalline, or thin-film.
EfficiencyVaries depending on the type of PV material used.
Lifespan20-25 years.
AppearanceIntegrated into building materials like roofs, facades, and windows.
PerformanceDual functionality as both building material and energy generator.
CostHigher initial cost due to integration into building structure.
ApplicationsNew construction and retrofitting of buildings with integrated solar capabilities.


These various types of solar panels cater to different needs, environments, and budgets, offering flexibility for diverse solar energy applications. Welcome to contact us!
